JENOPTIK JENar F-Theta Field Lens 347mm Large Format 1030-1080nm Laser

JENOPTIK JENar F-Theta Field Lens 347mm Large Format 1030-1080nm Laser

Products - Laser Scanning & Optics - Field Lenses
  • Highlight

    JENOPTIK JENar 1030-1080nm Field Lens

    ,

    JENOPTIK JENar 347mm Field Lens

    ,

    JENOPTIK JENar Large Format Field Lens

  • Model
    JENar 017700 Series (F=347)
  • Focal Length
    347 Mm
  • Working Field
    Large Format (~180×180 Mm Class)
  • Wavelength
    1030–1080 Nm
  • Shipping Term
    International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
  • Freight Charge
    For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
  • Place of Origin
    Germany
  • Brand Name
    JENOPTIK
  • Certification
    CE、RoHS、ISO
  • Model Number
    F347-017700-022-26
  • Minimum Order Quantity
    1
  • Price
    $1500 - $3500
  • Packaging Details
    Original
  • Delivery Time
    3-5Workdays
  • Payment Terms
    L/C,D/A,D/P,T/T

JENOPTIK JENar F-Theta Field Lens 347mm Large Format 1030-1080nm Laser

  • JENOPTIK JENar F-Theta Field Lens 347mm Large Format 1030-1080nm Laser
Get Price Chat Now
JENOPTIK JENar F-Theta Field Lens 347mm Large Format 1030-1080nm Laser

This JENar series F-Theta field lens (laser scanning focusing lens) from JENOPTIK, Germany, features a 347 mm focal length—a large-format model designed for big-area laser marking, cutting, and engraving systems. The lens includes a bright blue anodized aluminum front ring and a matte-black rear barrel, with multi-element high-performance optical glass optimized for 1030 nm - 1080 nm wavelengths. It maintains low-distortion focus and uniform spots across a large scanning field.

The F=347 mm configuration is ideal for large-sheet marking, signage engraving, and big-workpiece identification, and is recommended for use with 14-25 mm aperture scanners. As a genuine German import with full traceability, it pairs effectively with SCANLAB large-aperture scanners for complete large-format scanning systems.

Product Highlights
• Genuine German JENOPTIK: World-leading optics company with proven large-format JENar quality.
• Large Format, High Efficiency: 347 mm focal length significantly enlarges the scanning field.
• Low Distortion Design: Field-wide focus consistency with no edge drift.
• Fiber Laser Optimized: 1030-1080 nm coated optics for mainstream fiber lasers.
• Durable Build: Anodized aluminum housing for continuous workshop production.
• System Matching: Can be supplied with large-aperture scanners (intelliSCAN III 20/25 class) as a set.
Full Specifications & Parameters
Parameter Specification
Brand JENOPTIK (Germany)
Series JENar
Product Type F-Theta Field Lens (Laser Scanning Focusing Lens)
Model JENar 017700 series (F=347; confirm exact code with supplier)
Focal Length f 347 mm
Wavelength Range 1030 nm ≤ λ ≤ 1080 nm
Working Field Large format, typical ~180×180 mm class (per official datasheet)
Input Beam Typical for 14-25 mm aperture scanners (per datasheet)
Lens Construction Multi-element optical glass
Housing Material Anodized aluminum (blue front ring + black barrel)
Mount Standard thread / flange
Transmission High-transmission coatings (typical, per official data)
Origin Germany
Application Areas
  • Large-Format Marking: large sheets, structural metal parts, cabinet housings
  • Signage & Decorative Engraving: acrylic, wood and stone in large formats
  • Sheet Metal Cutting: large-format thin-sheet fiber laser cutting
  • Large Auto Parts Marking: body parts, large molds
  • PV Module Marking: solar panels and battery module traceability
  • Heavy Industrial Identification: construction machinery, containers, pipes
Frequently Asked Questions
Q: What is the exact field of F=347 mm?
A: Typical ~180×180 mm class; exact values per the official datasheet. Large formats mean a relatively larger spot—best for large-part marking.
Q: What scanner aperture is required?
A: We recommend 14-25 mm aperture scanners (e.g., SCANLAB intelliSCAN III 20/25 class) to maintain spot quality over large fields.
Q: Can it mark fine small text?
A: Large-format lenses produce a larger focused spot; for fine marks choose short-focal models (F=100/125/160). This model prioritizes large-area efficiency.
Q: Which lasers does it suit?
A: Suits 1030-1080 nm fiber lasers; UV or CO2 lasers require the corresponding wavelength version of the lens.
Q: Warranty and after-sales?
A: Genuine import with warranty per contract; technical support and lens inspection services available.
Q: Lead time?
A: German import; typical 1-2 weeks (depends on stock and logistics); bulk orders can be pre-stocked.
