JENOPTIK JENar F-Theta Field Lens 160mm 1030-1080nm Fiber Laser Marking
-
Highlight
Field Lens 160mm
,1080nm Fiber Laser Marking Field Lens
-
ModelJENar 017700 Series (F=160)
-
Focal Length160 Mm
-
Wavelength1030–1080 Nm
-
Product TypeF-Theta Field Lens
-
OriginGermany (genuine Import)
-
Shipping TermInternational Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
-
Freight ChargeFor Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
-
Place of OriginGermany
-
Brand NameJENOPTIK
-
CertificationCE、RoHS、ISO
-
Model NumberF160-01700-018-26
-
Minimum Order Quantity1
-
Price$2000 - $4000
-
Packaging DetailsOriginal
-
Delivery Time3-5Workdays
-
Payment TermsL/C,D/A,D/P,T/T
JENOPTIK JENar F-Theta Field Lens 160mm 1030-1080nm Fiber Laser Marking
JENOPTIK JENar F-Theta Field Lens 160mm 1030-1080nm Fiber Laser Marking
This JENar series F-Theta field lens (laser scanning focusing lens) from JENOPTIK, Germany, features a 160 mm focal length – a mid-short model that balances working field and spot quality. Widely used in fiber laser marking, engraving, and fine cutting systems, the lens delivers exceptional performance with its bright blue anodized aluminum front ring and matte-black rear barrel.
Constructed with multi-element high-performance optical glass coated for 1030 nm - 1080 nm wavelengths, it provides low-distortion, high-uniformity focusing across a medium field. As a genuine German import with full traceability, it mounts directly to mainstream galvo scanners to form a complete scanning optical path.
Product Highlights
- Genuine German JENOPTIK: World-leading optics and photonics company with proven JENar quality
- Balanced Field & Precision: F=160 mm sits between F=125 and F=255 – a versatile all-rounder
- Low Distortion, High Uniformity: F-Theta design for field-wide consistency
- Fiber Laser Optimized: 1030-1080 nm coated optics for mainstream fiber lasers
- Durable Build: Anodized aluminum housing for continuous production environments
- Easy Integration: Standard mount design for direct replacement and compatibility
Full Specifications & Parameters
| Parameter | Specification |
|---|---|
| Brand | JENOPTIK (Germany) |
| Series | JENar |
| Product Type | F-Theta Field Lens (Laser Scanning Focusing Lens) |
| Model | JENar 017700 series (F=160; confirm exact code with supplier) |
| Focal Length f | 160 mm |
| Wavelength Range | 1030 nm ≤ λ ≤ 1080 nm |
| Working Field | Typical ~90×90 mm class (per official datasheet) |
| Input Beam | Typical for 10-14 mm galvo scanners (per datasheet) |
| Lens Construction | Multi-element optical glass |
| Housing Material | Anodized aluminum (blue front ring + black barrel) |
| Mount | Standard thread / flange |
| Transmission | High-transmission coatings (typical, per official data) |
| Origin | Germany |
Application Areas
- Medium-Format Marking: Hardware, molds, nameplates, housings
- Precision Engraving: Crafts, knives, leather textures
- Traceability Marking: QR codes, serial numbers, anti-counterfeit codes
- Fiber Laser Cutting: Fine small-part thin-sheet cutting
- Automotive Parts Marking: Components and fasteners
- R & D: Beam scanning and focusing systems
Frequently Asked Questions
Q: What field size does F=160 mm suit?
A: Typical ~90×90 mm class for small-to-medium parts; confirm with the official datasheet.
Q: F=125, F=160 or F=255 – which one?
A: F=125 is finer with a smaller field; F=255 has a larger field with a coarser spot; F=160 is the versatile middle ground.
Q: Which lasers and scanners does it pair with?
A: Suits 1030-1080 nm fiber lasers and SCANLAB basiCube / intelliSCAN class 10-14 mm scanners.
Q: Mounting standard?
A: Standard thread/flange mount; most equivalent lenses are interchangeable. Send your barrel spec and we will confirm.
Q: Warranty and after-sales?
A: Genuine import with warranty per contract; technical support and lens inspection services available.
Q: Lead time?
A: German import; typical 2-4 weeks (depends on stock and logistics); bulk orders can be pre-stocked.
