JENOPTIK JENar F-Theta Field Lens 170mm 1030-1080nm Fiber Laser Marking
-
Highlight
Marking F-Theta Field Lens
,1080nm F-Theta Field Lens
-
ModelJENar 017700 Series (F=170)
-
Focal Length170 Mm
-
Wavelength1030–1080 Nm
-
Product TypeF-Theta Field Lens
-
Shipping TermInternational Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
-
Freight ChargeFor Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
-
Place of OriginGermany
-
Brand NameJENOPTIK
-
CertificationCE、RoHS、ISO
-
Model NumberF170-017700-018-26
-
Minimum Order Quantity1
-
Price$2500 - $4000
-
Packaging DetailsOriginal
-
Delivery Time3-5Workdays
-
Payment TermsL/C,D/A,D/P,T/T
JENOPTIK JENar F-Theta Field Lens 170mm 1030-1080nm Fiber Laser Marking
This is a JENar series F-Theta field lens (laser scanning focusing lens) from JENOPTIK, Germany, with a 170 mm focal length — a mid-format all-round model widely used in fiber laser marking, engraving and cutting systems. The lens features a bright blue anodized aluminum front ring and a matte-black rear barrel, with multi-element high-performance optical glass coated for 1030 nm – 1080 nm, providing wide-field, low-distortion, high-uniformity scanning focus. F=170 mm balances field size and spot quality between F=160 and F=255, making it a common configuration for marking machine builders and end users. A genuine German import with full traceability, it mounts directly to mainstream galvo scanners to form a complete scanning optical path.
- Genuine German JENOPTIK: world-leading photonics company; the JENar series is an industry benchmark.
- Balanced Mainstream Focal: F=170 mm — a popular configuration balancing field and spot, between F=160 and F=255.
- Low Distortion, High Uniformity: field-wide focus consistency with no edge drift.
- Fiber Laser Optimized: 1030–1080 nm coated optics for mainstream fiber lasers.
- Durable Build: anodized aluminum housing for continuous workshop use.
- Easy Integration: standard mount, direct replacement.
| Parameter | Specification |
|---|---|
| Brand | JENOPTIK (Germany) |
| Series | JENar |
| Product Type | F-Theta Field Lens (Laser Scanning Focusing Lens) |
| Model | JENar 017700 series (F=170; confirm exact code with supplier) |
| Focal Length f | 170 mm |
| Wavelength Range | 1030 nm ≤ λ ≤ 1080 nm |
| Working Field | Typical ~95×95 mm class (per official datasheet) |
| Input Beam | Typical for 10–14 mm galvo scanners (per datasheet) |
| Lens Construction | Multi-element optical glass |
| Housing Material | Anodized aluminum (blue front ring + black barrel) |
| Mount | Standard thread / flange |
| Transmission | High-transmission coatings (typical, per official data) |
| Origin | Germany |
- General Laser Marking: metal/non-metal identification, nameplates, serial numbers.
- Traceability Marking: QR codes, barcodes, anti-counterfeit codes.
- Laser Engraving: molds, crafts, wood and leather.
- Fiber Laser Cutting: mid-format thin-sheet cutting.
- Automotive / 3C Marking: auto parts and electronic components.
- Welding Focus: beam focusing in galvo welding systems.
- Q: What field size does F=170 mm cover? A: Typical ~95×95 mm class — between F=160 and F=255; confirm with the official datasheet.
- Q: Which lasers and scanners does it pair with? A: Suits 1030–1080 nm fiber lasers and SCANLAB basiCube / intelliSCAN class 10–14 mm scanners.
- Q: F=170 mm vs F=160 mm / F=255 mm? A: F=160 is slightly smaller with a finer spot; F=255 offers a larger field (114×114) with a coarser spot; F=170 is the balanced middle ground.
- Q: How long do the coatings last? A: With normal use and cleaning, coating life matches the machine; avoid contamination and direct laser damage.
- Q: Warranty and after-sales? A: Genuine import with warranty per contract; technical support and lens inspection services are available.
- Q: Lead time? A: German import; typical 1 weeks (depends on stock and logistics); bulk orders can be pre-stocked.
