SCANLAB basiCube 10 Compact Galvo Scanner Head Laser Marking 532nm 1064nm
-
Highlight
Compact Galvo Scanner Head
,Laser Marking Galvo Scanner Head
,532nm Galvo Scanner Head
-
ModelBasiCube 10
-
Aperture10 Mm
-
Wavelength532nm / 1064nm
-
WarrantyPer Contract (genuine Product)
-
Shipping TermInternational Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
-
Freight ChargeFor Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
-
Place of OriginGermany
-
Brand NameSCANLAB
-
CertificationCE、 RoHS、ISO
-
Model NumberbasiCube 10
-
Minimum Order Quantity1
-
Price$3000 - $7000
-
Packaging DetailsOriginal
-
Delivery Time3-5Workdays
-
Payment TermsL/C,D/A,D/P,T/T
SCANLAB basiCube 10 Compact Galvo Scanner Head Laser Marking 532nm 1064nm
SCANLAB basiCube 10 Compact Galvo Scanner Head Laser Marking 532nm 1064nm
Product Overview
The basiCube 10 is a compact laser scanning galvanometer (scan head) from SCANLAB, Germany. Its integrated rectangular body with a cylindrical flange base delivers a lightweight, space-saving solution — an excellent value choice among genuine SCANLAB scan heads for laser marking and engraving.
The die-cast/machined aluminum housing with coated surface offers good heat dissipation and EMI shielding. A multi-pin D-sub connector on the side handles power and signals, the front face houses the beam output aperture, and the bottom flange mounts a field lens directly to form a complete scanning optical path. The basiCube 10 supports 532 nm (green) and 1064 nm (IR) wavelengths, and works with standard digital control interfaces.
Product Highlights
- Genuine German Import: SCANLAB original manufacturing, industrial-grade reliability, serial-number traceability.
- Compact & Efficient: Integrated body + flange base saves mounting space, ideal for compact marking systems.
- Dual Wavelength: 532 nm green and 1064 nm IR cover mainstream fiber and solid-state lasers.
- Easy Integration: Flange base mounts a field lens directly; standard D-sub wiring; quick setup.
- Great Value: The basiCube series is SCANLAB's entry-level workhorse — original quality at a friendlier price.
- Reliable Cooling: Aluminum housing with natural convection keeps long-run marking stable.
Technical Specifications
| Brand | SCANLAB (Germany) |
|---|---|
| Model | basiCube 10 |
| Product Type | Galvanometer Scanner / Scan Head |
| Aperture | 10 mm |
| Wavelengths | 532 nm (green), 1064 nm (IR) |
| Max. Scan Angle | Typical ±0.35 rad (adjustable) |
| Control Interface | Digital (XY2-100 compatible) |
| Signal/Power Connector | Side multi-pin D-sub |
| Structure | Rectangular body + cylindrical flange base (field-lens mount) |
| Housing Material | Die-cast / machined aluminum, coated finish |
| Cooling | Natural convection (aluminum housing) |
| Operating Temperature | Industrial environment (typical 10-40°C) |
| Origin | Germany |
Application Areas
- Laser Marking: Text, graphics, QR codes and serial numbers on metal and non-metal surfaces.
- Laser Engraving: Molds, nameplates, crafts and fine electronic-component engraving.
- Laser Cutting: Beam deflection for thin-sheet precision cutting.
- Laser Welding: Beam scanning for low-power spot/seam welding.
- 3D Printing / Additive Manufacturing: Galvo-scanned laser sintering/curing systems.
- R & D: Laboratory optical scanning and beam-control platforms.
Frequently Asked Questions
Which laser wavelengths does the basiCube 10 support?
It supports 532 nm (green) and 1064 nm (IR), compatible with common fiber and solid-state lasers.
Will it work with my existing control card?
It uses a digital interface (XY2-100 compatible) and matches mainstream galvo control cards. Send us your control-card model and we will confirm compatibility.
What is the maximum scan angle?
Typically ±0.35 rad (approx. ±20°), adjustable via control software to set your working field.
Warranty and after-sales?
Genuine-product guarantee with warranty per contract.
Lead time?
German import; typical lead time 2-4 weeks (depending on stock and logistics). The SN is a unique code; the actual unit received prevails.
Which field lens should I pair?
The bottom flange mounts an F-Theta lens directly. We can recommend a matching field lens (e.g., Linos / Sigma series) based on your marking field size.
