Product Details
Place of Origin: Japan
Certification: RoHS, CE, UL, UKCA, ATEX
Model Number: GP6000
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $400 - $2500
Delivery Time: 3-5Workday
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
HMI Touch Screen
|
Screen Size:
|
5.7/7.5/10.4/12.1/10/12/15/19
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
HMI Touch Screen
|
|
Screen Size:
|
5.7/7.5/10.4/12.1/10/12/15/19
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
GP6000 HMI Touch Screen- Fast Startup & Smooth Operation | Industrial Automation
| Category | Item | Standard Model | Advanced Model |
|---|---|---|---|
| Display Specifications | Size | 5.7"/7.5"/10.4"/12.1" (4:3 Aspect Ratio) | 7" Wide/10" Wide/12" Wide/15" Wide/19" Wide/22" Wide/15"/12.1"/10.4"/DINBOX |
| Resolution | 5.7"/7.5": 640*480; 10.4"/12.1": 800*600 | Wide Screen: 1280*800 (7")/1920*1080 (10"/12"/15"/19"/22"); 4:3: 800*600 (10.4"/12.1")/1024*768 (15") | |
| Display Type | Color TFT LCD, LED Backlight | Color TFT LCD, LED Backlight | |
| Touch Panel | Analog Resistive (Single-Touch) | Analog Resistive (Single-Touch)/Matrix (Dual-Touch) | |
| Backlight Life | Approx. 50,000 Hours (White Backlight) | Approx. 50,000 Hours (White Backlight) | |
| System Performance | Processor | High-Performance Industrial-Grade Processor | High-Performance Industrial-Grade Processor (Faster Computing) |
| Startup Time | 10.4 Seconds (87% Faster Than GP4000-T) | 10.4 Seconds (87% Faster Than GP4000-T) | |
| Screen Refresh Rate | 0.06 Seconds (97% Improvement Over GP4000-T) | 0.06 Seconds (97% Improvement Over GP4000-T) | |
| Software Compatibility | Compatible with GP-Pro EX Software | Compatible with GP-Pro EX Software | |
| Electrical Specifications | Rated Voltage | DC 24V (19.2-28.8V) | DC 24V (19.2-28.8V)/AC 100-240V |
| Max Power Consumption | 13.5W (10.4", Model PFXGP6600TAD) | Varies by Model; Slightly Higher for Wide-Screen Models | |
| Shock/Vibration Resistance | Compliant with Industrial Standards | Compliant with Industrial Standards | |
| Ethernet | 100M Ethernet (RJ45) | Gigabit Ethernet (RJ45) | |
| Serial Port | COM1 (RS232C), COM2 (RS422/RS485) | COM1 (RS232C), COM2 (RS422/RS485) | |
| Communication Interfaces | USB Port | USB Type-A *1, USB Micro-B *1 | USB Type-A *1, USB Micro-B *1 |
| Expansion Storage | Supports SDXC Card | Supports SDXC Card | |
| Expansion Interface | None | Supports DINBOX Expansion Modules | |
| Environment & Certifications | Protection Level | Front Panel IP65F | Front Panel IP65F |
| Operating Temperature | 0-45℃ | 0-45℃ | |
| Certifications | CE, UL, UKCA, ATEX, RoHS, etc. | CE, UL, UKCA, ATEX, RoHS, etc. |
| Model No. | Display Size & Resolution | Touch Panel Type | Power Supply | Key Features |
|---|---|---|---|---|
| PFXGP6600TMD | 12.1" (1024*768) | Matrix Dual-Touch | DC 12-24V | 2*COM ports, 2*100M Ethernet ports, USB & SDXC support |
| PFXGP6600TMA | 12.1" (1024*768) | Matrix Dual-Touch | AC 100-240V | Same as PFXGP6600TMD, AC power supply |
| PFXGP6600TAD | 12.1" (1024*768) | Analog Single-Touch | DC 12-24V | Basic configuration, cost-effective option |
| PFXGP6600TAA | 12.1" (1024*768) | Analog Single-Touch | AC 100-240V | Same as PFXGP6600TAD, AC power supply |
| PFXGP6500TMD | 10.4" (800*600) | Matrix Dual-Touch | DC 12-24V | Compact size, suitable for limited installation space |
| PFXGP6500TMA | 10.4" (800*600) | Matrix Dual-Touch | AC 100-240V | Same as PFXGP6500TMD, AC power supply |
| PFXGP6500TAD | 10.4" (800*600) | Analog Single-Touch | DC 12-24V | Entry-level model with essential functions |
| PFXGP6500TAA | 10.4" (800*600) | Analog Single-Touch | AC 100-240V | Same as PFXGP6500TAD, AC power supply |
| PFXGP6400TAD | 7.5" (640*480) | Analog Single-Touch | DC 12-24V | Miniature design for small machinery |
| PFXGP6300TAD | 5.7" (640*480) | Analog Single-Touch | DC 12-24V | Ultra-compact, ideal for space-constrained applications |
| Model No. | Display Size & Resolution | Touch Panel Type | Power Supply | Application Scenario |
|---|---|---|---|---|
| PFXGP6600TAD-FZ26 | 12.1" (1024*768) | Analog Single-Touch | DC 12-24V | Semiconductor industry, N₂ protection support |
| PFXGP6600TADC | 12.1" (1024*768) | Analog Single-Touch | DC 12-24V | Coated panel, enhanced durability for harsh environments |
| PFXGP6500TADC | 10.4" (800*600) | Analog Single-Touch | DC 12-24V | Coated panel, suitable for dusty/wet industrial sites |
| Model No. | Display Size & Resolution | Touch Panel Type | Status | Key Advantage |
|---|---|---|---|---|
| PFXGP6940WCAI/WCDI | 19" Wide (1920*1080) | Analog Single-Touch/Dual-Touch | Available | Large wide-screen, high resolution for complex operations |
| PFXGP6840WCAI/WCDI | 15" Wide (1920*1080) | Analog Single-Touch/Dual-Touch | Available | Balanced size & performance, versatile for multiple industries |
| PFXGP6740WCAI/WCDI | 12" Wide (1920*1080) | Analog Single-Touch/Dual-Touch | Upcoming | Slim wide-screen design, space-saving |
| PFXGP6540WCAI/WCDI | 10" Wide (1920*1080) | Analog Single-Touch/Dual-Touch | Available | Compact wide-screen, clear display for precision operations |
| PFXGP6B40AI/DI | Box-type (No Built-in Display) | N/A | Available | Modular design, easy integration with external displays |
