Product Details
Place of Origin: China
Certification: CE, FCC, UL, RoHS, KC, CB
Model Number: XL5H
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $360- $420
Delivery Time: 3-5workdays
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
|
Type:
|
Programmable Logic Controller
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Programmable Logic Controller
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Parameter Category | Item | Specification |
|---|---|---|
| Basic Performance | User Program Capacity | 1 MB (FlashROM) |
| Basic Instruction Execution Speed | 0.01–0.05 μs | |
| Program Execution Mode | Cyclic scanning mode | |
| Max. I/O Points | 536 points | |
| Power Supply | Rated Operating Voltage | DC 24 V (20.4–28.8 V) |
| Power Input Type | DC 24 V, wide-range voltage input | |
| Power Protection | Over-voltage/over-current/short-circuit protection | |
| I/O & Expansion | Native I/O (XL5H-24A8L) | 24 points (12 NPN inputs, 12 transistor outputs) |
| High-Speed Counter | 3 channels (single-phase max. 80 kHz, AB phase max. 50 kHz) | |
| Pulse Output | 2 axes, max. 100 kHz (Y0-Y1) | |
| Expansion Capability | Right: 16 modules; Left: 1 module | |
| EtherCAT Bus | Protocol | EtherCAT (CoE, PDO, SDO supported) |
| Communication Rate | 100 Mbps (100BASE-TX, full-duplex) | |
| Max. Slave Stations | 127 stations | |
| Cycle Time | Min. 1 ms; Synchronization Jitter < 1 μs | |
| Station-to-Station Distance | ≤ 100 m (CAT5e/CAT6 cable) |
