Product Details
Place of Origin: China
Certification: CE、RoHS、FCC、UL、KC、CSA、ATEX
Model Number: XSFQ7
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $180 - $720
Delivery Time: 3-5workdays
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
Programmable Logic Controller
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Programmable Logic Controller
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Category | Core Parameters |
|---|---|
| Motion Control Capability | Supported Axes: Max 32-axis coordinated control Interpolation Functions: Linear interpolation, circular interpolation, helical interpolation Pulse Output: Max 10MHz output frequency, supporting pulse/direction and dual-pulse modes |
| Bus Protocol Support | Synchronous Serial Protocols: SSI, BiSS C, EnDat 2.x Incremental Encoder: A/B/Z quadrature signal, supporting x1/x2/x4 decoding modes Industrial Bus: EtherCAT, Profinet (compatible with mainstream industrial standards) |
| Communication Interfaces | Ethernet Interface: 2× Gigabit Ethernet (1000Mbps auto-adaptive) Serial Interface: 2× RS485, 1× RS232 High-Speed Interface: 25MHz SPI interface, 16Mbit/s UART interface |
| Storage Specifications | Program Memory: 64MB Flash Data Memory: 128MB DDR2 SDRAM Expansion Storage: Support local U-disk storage and program import/export |
| Digital I/O Configuration | Built-in I/O: 24× digital inputs, 16× digital outputs (with overcurrent protection) Expansion Capability: Max support for 4096 input/4096 output isolated I/O expansion |
| Analog Interface | Analog Input: 4 channels (0-10V, 0.2% accuracy) Analog Output: 2 channels (0-10V, 0.5% accuracy) Refresh Time: ≤10ms |
| Hardware Specifications | Supply Voltage: 24V DC (wide voltage range 18-30V) Power Consumption: ≤12W (fanless heat dissipation) Operating Temperature: -40℃~+125℃ Package Size: 180×120mm (compact blade-type design) |
| Core Performance | Operation Speed: 0.02μs per instruction Position Resolution: 64-bit encoder counting Communication Latency: ≤7ns (bus synchronization latency) Programming Environment: Support multi-task programming and custom protocol development |
| Product Model | Supported Axes | Core Function Version | Compatible Bus Protocol | Key Configuration Highlights | Overseas Certification Standards |
|---|---|---|---|---|---|
| XSFQ7-2S-E | 2-axis | Standard Version | EtherCAT | Basic linear/circular interpolation, 24-channel digital I/O, 64MB Flash memory | CE, RoHS, FCC |
| XSFQ7-2S-P | 2-axis | Standard Version | Profinet | Profinet IO compatible, 10MHz pulse output, U-disk program import/export supported | CE, RoHS, TÜV |
| XSFQ7-4P-E | 4-axis | Enhanced Version | EtherCAT | 4-axis coordinated control, 64-bit position resolution, communication latency ≤7ns | CE, RoHS, FCC, UL |
| XSFQ7-4P-P | 4-axis | Enhanced Version | Profinet | High-precision synchronous control, SSI/BiSS C encoder supported | CE, RoHS, TÜV, UL |
| XSFQ7-8P-E | 8-axis | Enhanced Version | EtherCAT | 8-axis coordination + helical interpolation, 128MB DDR2 memory, dual Gigabit Ethernet ports | CE, RoHS, FCC, UL, KC |
| XSFQ7-8P-P | 8-axis | Enhanced Version | Profinet | EnDat 2.x protocol supported, 4-channel analog input, overcurrent protection for outputs | CE, RoHS, TÜV, UL, KC |
| XSFQ7-16H-E | 16-axis | Advanced Version | EtherCAT | 16-axis synchronous control, custom protocol development, 4096-point I/O expansion support | CE, RoHS, FCC, UL, KC, CSA |
| XSFQ7-16H-P | 16-axis | Advanced Version | Profinet | Multi-task programming, high-speed SPI/UART interfaces, wide-temperature operation (-40℃~+125℃) | CE, RoHS, TÜV, UL, KC, CSA |
| XSFQ7-32H-E | 32-axis | Advanced Version | EtherCAT | 32-axis max coordination, 0.02μs/instruction operation speed, redundant communication | CE, RoHS, FCC, UL, KC, CSA, ATEX |
| XSFQ7-32H-P | 32-axis | Advanced Version | Profinet | Full protocol compatibility, hot-swappable expansion supported, low power consumption ≤12W | CE, RoHS, TÜV, UL, KC, CSA, ATEX |
