Product Details
Place of Origin: France
Certification: CE、UL 61010-2-201、UL508、CSA-E 1131-2、CSA 22.2 No.142、CSA 22.2 No.213（ Class I Division 2）、RCM
Model Number: BMKC8020301 BMKC8020310 BMKC8030311
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $1000-$1800
Delivery Time: 3-5workdays
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
|
Type:
|
Programmable Logic Controller
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Programmable Logic Controller
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Parameter Category | Specific Parameter | Details |
|---|---|---|
| Core Performance | Processor | 64-bit high-performance processor; Boolean instruction execution time: 0.06µs; Mixed instruction execution time: 0.08µs |
| Memory Configuration | Total internal RAM: 3840KB; Program/Constant Storage: 3590KB; Data Storage: 128KB | |
| Memory Retention | Battery-free long-term retention for stable data preservation | |
| Power Supply | Supply Voltage | 24V DC, voltage range: 20.4~28.8V (supports ±15%~20% fluctuation) |
| Power Consumption | Maximum current draw ≤ 700mA | |
| Isolation Voltage | 1500V DC for enhanced anti-interference capability | |
| Input/Output (I/O) | Digital Inputs | 8 channels (sinking current), Type 3; Voltage range: 19~30V DC; Operating current: 2.4mA |
| Digital Outputs | 12 channels (sourcing output); Voltage range: 19~30V DC; Single-channel current: 2A; Total module current: 10A; Overload/short-circuit protection supported | |
| Analog Inputs | 4 channels; Supports -20~20mA current input, -10~10V voltage input; 16-bit resolution | |
| Analog Input Response | Fast reading cycle: 1.3ms + 1.3ms * number of channels used; Nominal reading cycle for 4 channels: 6.5ms | |
| High-Speed Counters | 2 channels supported; Compatible with 24V 2-wire/3-wire proximity sensors and push-pull output incremental encoders (10~30V); 2 sourcing outputs provided (0.5A per channel) | |
| Communication Interfaces | Ethernet | 2 industrial Ethernet ports with built-in switch; Native support for RSTP ring topology redundancy |
| Serial Interfaces | 1 RS-232 port, 1 RS-485 port (supports Modbus Master/Slave modes) | |
| Dedicated Interface | 1 CANopen Master port for connecting encoders, inverters, and other devices | |
| Other Interfaces | 1 USB port for local debugging and configuration | |
| Environmental | Operating Temperature | -25℃ ~ +70℃, suitable for harsh mirror field environments in CSP plants |
| Protection Certifications | Compliant with CE, UL, CSA No 213 Class I Division 2, and IEC standards | |
| Physical & Software | Dimensions | Width: 220mm; Compact design saves installation space |
| Weight | Approximately 1.05kg | |
| Programming Software | Compatible with Unity Pro (EcoStruxure Control Expert) programming platform | |
| Supplementary Functions | Supports SG Backup for fast program copying, cloning, and management; Built-in "Solar Library" with preconfigured function blocks |
| Model | Digital Input (DI) | Digital Output (DO) | Analog Input (AI) | High-Speed Counter (HSC) | Core Configuration Features | Application Scenarios |
|---|---|---|---|---|---|---|
| BMKC8020301 | 8 | 12 | 4 | / | 2 RJ45 Ethernet ports (supporting RSTP, Modbus TCP), 1 CANopen port, 1 RS232/RS485 serial port, 3840KB user memory, operating temperature -25~+70℃, 16-bit analog input resolution, 2A per DO output (10A total per module) | Small-scale automation scenarios requiring analog acquisition + digital control, such as small production lines, packaging equipment control, and thermo solar - parabolic through systems |
| BMKC8020310 | 8 | 8 | / | 2 (60kHz max) | 2 high-speed counters (up to 60kHz), 2 Ethernet ports, 1 CANopen port, 3840KB user memory, operating temperature -25~+70℃, 2A per DO output | Small equipment control scenarios needing high-speed counting, like motor speed monitoring, material counting, and short-distance conveyor belt control |
| BMKC8030311 | 8 | 12 | 4 | 2 (60kHz max) | Integrated 8DI+12DO+4AI+2HSC, dual Ethernet + CANopen + serial port, supports Modbus TCP/CANopen/RS485 protocols, wide temperature adaptation, 10A total module output current | Complex small-scale automation scenarios, such as photovoltaic thermal tower power generation equipment, multi-axis small motion control devices |
| BMKC8020300 (Old Model) | 8 | 12 | 4 | / | Previous generation of BMKC8020301 with the same functions, now discontinued and replaced | Only for old equipment replacement, no new application scenarios |
| BMKC8030310 (Old Model) | 8 | 12 | 4 | 2 | Previous generation of BMKC8030311 with the same functions, now discontinued and replaced | Only for old equipment replacement, no new application scenarios |
