Product Details
Place of Origin: CHina
Brand Name: INVT
Certification: CE UL/cUL TÜV EMC EAC
Model Number: GD28
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $65 – $1800
Delivery Time: 3-5Workdays
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Product Name:
|
Frequency Converter Inverter
|
Warranty:
|
Original Factory Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Product Name:
|
Frequency Converter Inverter
|
|
Warranty:
|
Original Factory Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Power Range | Single-phase 200-240V 0.2-4kW Three-phase 200-240V 0.2-15kW Three-phase 380-480V 0.4-22kW |
| Overload Capacity | Light Duty: 110% rated current for 60s Heavy Duty: 150% rated current for 60s |
| Control Modes | V/F control, Sensorless Vector Control (SVC) |
| Starting Torque | 200% starting torque at 0.5Hz |
| Torque Response | <10ms |
| Operating Temperature | Full load operation at 50°C ambient temperature, no derating required |
| Model Code | Power (kW) | Frame Size | Description |
|---|---|---|---|
| GD28-0R2G-S2 | 0.2 kW | A | Entry-level single-phase drive for small motor control |
| GD28-0R4G-S2 | 0.4 kW | A | Suitable for light equipment such as fans and small conveyors |
| GD28-0R7G-S2 | 0.75 kW | A | Smooth speed regulation for small equipment applications |
| GD28-1R1G-S2 | 1.1 kW | A | Medium-power single-phase model for moderate loads |
| GD28-1R5G-S2 | 1.5 kW | A | Meets heavier light-industrial load requirements |
| GD28-2R2G-S2 | 2.2 kW | B | High-power single-phase drive for complex equipment |
| GD28-004G-S2 | 4.0 kW | B | Maximum power in single-phase series, industrial-grade applications |
| Model Code | Power (kW) | Frame Size | Description |
|---|---|---|---|
| GD28-0R2G-2 | 0.2 kW | A | Three-phase version for small motor systems |
| GD28-0R4G-2 | 0.4 kW | A | Basic three-phase drive |
| GD28-0R7G-2 | 0.75 kW | A | Suitable for general industrial equipment |
| GD28-1R1G-2 | 1.1 kW | A | Standard model with stable performance |
| GD28-1R5G-2 | 1.5 kW | A | Suitable for conveyors, mixers, etc. |
| GD28-2R2G-2 | 2.2 kW | A | Medium-power industrial applications |
| GD28-004G-2 | 4.0 kW | B | Standard industrial load drive |
| GD28-5R5G-2 | 5.5 kW | C | Higher power model |
| GD28-7R5G-2 | 7.5 kW | C | Suitable for heavy machinery |
| GD28-011G-2 | 11 kW | D | High-power industrial drive |
| GD28-015G-2 | 15 kW | D | Maximum power in three-phase 200V series |
| Model Code | Power (kW) | Frame Size | Description |
|---|---|---|---|
| GD28-0R4G-4 | 0.4 kW | A | Economical entry-level three-phase 380V model |
| GD28-0R7G-4 | 0.75 kW | A | Common model for industrial HVAC and light equipment |
| GD28-1R1G-4 | 1.1 kW | A | Standard model for general automation |
| GD28-1R5G-4 | 1.5 kW | A | Suitable for conveyors, mixers, pumps |
| GD28-2R2G-4 | 2.2 kW | A | General-purpose model with strong torque |
| GD28-003G-4 | 3.0 kW | A | Suitable for various processing equipment |
| GD28-004G-4 | 4.0 kW | B | Efficient drive for continuous industrial loads |
| GD28-5R5G-4 | 5.5 kW | C | Designed for heavy industrial loads |
| GD28-7R5G-4 | 7.5 kW | C | Stable performance mid-power model |
| GD28-011G-4 | 11 kW | D | Large-capacity industrial drive |
| GD28-015G-4 | 15 kW | D | Suitable for heavy equipment |
| GD28-018G-4 | 18 kW | E | High-performance drive for demanding applications |
| GD28-022G-4 | 22 kW | E | Flagship model with maximum power in series |
| Frame Size | Typical Power Range (380V) | Installation Features |
|---|---|---|
| A | 0.4-3.0 kW | Ultra-compact design, supports seamless side-by-side installation |
| B | 4.0 kW | Compact design, supports seamless side-by-side installation |
| C | 5.5-7.5 kW | Standard industrial footprint |
| D | 11-15 kW | Larger chassis for enhanced heat dissipation |
| E | 18-22 kW | Maximum frame size in the series |
| Industry Sector | Specific Applications |
|---|---|
| Machine Tools | Spindle drive, feed axis control |
| Textile | Textile machinery, chemical fiber equipment |
| Printing & Packaging | Printing presses, packaging lines, labeling machines |
| Food & Beverage | Food processing, conveyors |
| Lithium Battery | Battery production equipment |
| Logistics | Sorting lines, conveyors |
| 3C Electronics | Electronic assembly lines |
| Rubber & Plastics | Extruders, injection molding machines |
| Wire & Cable | Wire drawing machines, stranding machines |
| HVAC | Fans, pumps, air conditioning systems |
| If you need... | Choose... |
|---|---|
| Single-phase 220V power supply | S2 suffix models (0.2-4kW) |
| Three-phase 200V power supply | -2 suffix models (0.2-15kW) |
| Three-phase 380V power supply | -4 suffix models (0.4-22kW) |
| Minimal installation space | Frame A models (≤3kW) |
| Seamless side-by-side installation | Frame A & B models |
| Maximum power requirements | Frame E models (18-22kW) |
