M2QA Servo Motor for HVAC, Water Treatment & Food Beverage Industry
-
Highlight
ABB M2QA servo motor HVAC
,servo drive motor water treatment
,food beverage industry servo motor
-
TypeServo Drive Motor
-
WarrantyOriginal Manufacturer's Warranty
-
PakageOriginal Pakage
-
Shipping TermInternational Express（DHL/FEDEX/TNT/UPS/ARAMEX）/sea Freight / Air Freight / International Special Line
-
Freight ChargeFor Industrial Equipment (e.g., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
-
Place of OriginSwedish
-
CertificationIEC、CE、UL、CSA、ABS、BV、DNV、LR
-
Model NumberM2QA
-
Minimum Order Quantity1
-
Price$100 - $25000
-
Delivery Time3-5Workday
-
Payment TermsL/C,D/A,D/P,T/T,Western Union
M2QA Servo Motor for HVAC, Water Treatment & Food Beverage Industry
M2QA Servo Motor
The M2QA Servo Motor is a high-efficiency, reliable solution engineered for HVAC, water treatment, and food beverage industries. Boasting IE5-level efficiency, IP55 protection, and compliance with IEC/CE standards, it delivers stable performance in harsh conditions, supports flexible mounting options, and seamlessly integrates with industrial systems to cut operational costs and boost productivity.
Core Features
- High Energy Efficiency: Efficiency class up to IE2-IE5, compliant with IEC, GB and other international & national standards, delivering outstanding energy-saving performance.
- Multi-scenario Adaptability: Fully enclosed three-phase squirrel cage design with IP55 protection rating, corrosion and moisture resistant, suitable for harsh working conditions in HVAC, water treatment, food & beverage and other industries.
- Reliable Structural Design: F-class insulated windings paired with deep groove ball bearings; models with center height 71-250mm are equipped with maintenance-free bearings to extend service life.
- Flexible Installation & Configuration: Supports multiple mounting methods (B3/B5/B35), rotatable terminal box, wide voltage range (up to 690V) compatible with 50/60Hz power grids.
Core Advantages
- Lower Operational Costs: Ultra-high efficiency enables users to recover procurement premium within 6-18 months, reducing long-term electricity expenses significantly.
- Stable & Low-maintenance: Global unified design platform ensures consistent quality and low failure rate; optional accessories like PTC thermal protection further minimize maintenance costs.
- Low Noise & Eco-friendly: Optimized electromagnetic and cooling system design reduces noise levels; production facilities are certified to ISO 9001 quality management system and ISO 14000 environmental standards.
- Customizable Compatibility: Supports optional accessories such as anti-condensation heaters and sealing rings; configurable according to industry-specific requirements for strong compatibility.
Core Technical Parameters
| Parameter Category | Specific Parameters | Description |
|---|---|---|
| Electrical Parameters | Motor Type | Three-phase asynchronous, totally enclosed squirrel cage type |
| Rated Power | 0.18KW - 355KW (Power range varies slightly with different pole numbers) | |
| Rated Voltage | 220V - 690V, supporting multiple voltage levels such as 220-240V/380-420V/440-480V/660-690V | |
| Rated Frequency | 50Hz / 60Hz Universal | |
| Energy Efficiency Class | IE2 - IE5 Optional, compliant with IEC/CE/GB and other standards | |
| Mechanical Parameters | Pole Number | 2-pole, 4-pole, 6-pole, 8-pole; corresponding rated speed around 3000/1500/1000 rpm |
| Mounting Method | Standard B3 (Foot Mount), B5 (Flange Mount), B35 (Foot + Flange Mount); supports custom non-standard mounting | |
| Frame Specification | Cast iron frame, center height H71 - H355mm | |
| Bearing Configuration | Deep groove ball bearings; models with center height 71-250mm are maintenance-free bearings, 280-355mm models with oil injection/drainage device | |
| Terminal Box | Protection class IP55; 71-132 models can rotate 4×90°, 160-355 models can rotate 2×180°; supporting top/left/right outlet | |
| Protection & Insulation | Protection Class | Standard IP55; customizable IP56/IP65 and other higher protection classes |
| Insulation Class | Class F insulation, Class B temperature rise (80K), maximum allowable winding temperature 155℃ | |
| Cooling Method | Totally enclosed self-cooling (IC411) | |
| Winding Protection | Standard 3 pcs 150℃ PTC thermistors; optional accessories such as anti-condensation heaters and thermal switches can be added | |
| Environmental & Operating Conditions | Operating Temperature | Ambient temperature -20℃ - 40℃, altitude not exceeding 1000m |
| Duty Cycle | Continuous duty (S1) | |
| Corrosion Resistance | High corrosion-resistant cast iron housing, suitable for harsh working conditions such as humidity and heavy dust | |
| Certification & Warranty | Product Certification | CE, IEC, ISO 9001, VDE, etc., meeting EU/international market access requirements |
| Warranty Period | Standard warranty 1 year, service life up to 10 years under normal working conditions |
Overseas Available Models
| Frame Size (Center Height mm) | Overseas Available Models | Core Configuration Reference |
|---|---|---|
| 71 | M2QA 71 M2A 3GQA 071 301, M2QA 71 M2B 3GQA 071 302, M2QA 71 M4B 3GQA 072 302 | Pole Number: 2P/4P; Frame Length: M; Core Length: A/B; Protection Class IP55, Class F Insulation |
| 80 | M2QA 80 M2A 3GQA 081 301, M2QA 80 M2B 3GQA 081 302, M2QA 80 M4A 3GQA 082 301, M2QA 80 M4B 3GQA 082 302 | Pole Number: 2P/4P; Frame Length: M; Core Length: A/B; Wide Voltage 220-420V, 50/60Hz Universal |
| 90 | M2QA 90 S2A 3GQA 091 101, M2QA 90 L2A 3GQA 091 501, M2QA 90 S4A 3GQA 092 101, M2QA 90 L4A 3GQA 092 501, M2QA1.1-90S4 | Pole Number: 2P/4P; Frame Length: S/L; Core Length: A; Power Range 0.75-1.5KW, Maintenance-Free Bearings |
| 100 | M2QA 100 L2A 3GQA 101 501, M2QA 100L4A, M2QA 100L4B, M2QA100L 2.2-4P, M2QA100L3KW-4B | Pole Number: 2P/4P; Frame Length: L; Core Length: A/B; Power Range 2.2-3KW, Supporting B3/B5 Mounting |
| 112 | M2QA 112 M2A 3GQA 111 301, M2QA 112 L2A 3GQA 111 501, M2QA 112 M4A, M2QA 112M2A 4KW | Pole Number: 2P/4P; Frame Length: M/L; Core Length: A; Power Around 4KW, IP55 Protection, Low-Noise Design |
| 132 | M2QA 132 S2A 3GQA 131 101, M2QA 132 S2B 3GQA 131 102, M2QA 132 M2A 3GQA 131 301, M2QA 132 M2B 3GQA 131 302, M2QA 132S4A, M2QA132M4A 7.5KW | Pole Number: 2P/4P; Frame Length: S/M; Core Length: A/B; Power 5.5-7.5KW, Terminal Box Rotatable 4×90° |
| 160 | M2QA 160 M2A 3GQA 161 301, M2QA 160 M2B 3GQA 161 302, M2QA 160 L2A 3GQA 161 501, M2QA 160 L2B 3GQA 161 502, M2QA160M4A 11KW, M2QA160L4A15KW | Pole Number: 2P/4P; Frame Length: M/L; Core Length: A/B; Power 11-18.5KW, Class F Insulation, Class B Temperature Rise |
| 180 | M2QA 180 M2A 3GQA 181 301, M2QA 180 L2A 3GQA 181 501, M2QA180M4A 18.5KW | Pole Number: 2P/4P; Frame Length: M/L; Core Length: A; Power 18.5-22KW, Supporting B3/B5/B35 Mounting |
| 200 | M2QA 200 L2A 3GQA 201 501, M2QA 200 L2B 3GQA 201 502, M2QA 200 L2C 3GQA 201 503, M2QA200L4A 30KW | Pole Number: 2P/4P; Frame Length: L; Core Length: A/B/C; Power 30KW, Wide Voltage 380-690V |
| 225 | M2QA 225 M2A 3GQA 221 301, M2QA 225 M2B 3GQA 221 302, M2QA225M4A45KW, M2QA225S4A 37KW | Pole Number: 2P/4P; Frame Length: M/S; Core Length: A/B; Power 37-45KW, With Oil Filling Hole Design |
| 250 | M2QA 250 M2A 3GQA 251 301, M2QA 250 M2B 3GQA 251 302, M2QA250M4A 55KW | Pole Number: 2P/4P; Frame Length: M; Core Length: A/B; Power 55KW, Corrosion-Resistant Cast Iron Frame |
| 280 | M2QA280S4A 75KW, M2QA280S 4 B3 75KW, M2QA280S4AB35 75KW | Pole Number: 4P; Frame Length: S; Power 75KW, IP55 Protection, Standard Drain Hole and Plug Configuration |
| 355 | M2QA355L6A 250KW | Pole Number: 6P; Frame Length: L; Power 250KW, High Power Rating, Suitable for Heavy-Duty Industrial Scenarios |
Application Fields
- HVAC Systems: Powers air handlers, chillers & cooling towers with stable speed control and IE5 efficiency, cutting energy costs for commercial/industrial climate management.
- Water Treatment: Drives water pumps, sludge mixers & aeration systems. IP55 protection resists humidity and corrosion, ideal for municipal water/wastewater plants.
- Food & Beverage: Fits conveyors, mixers & filling machines. Low noise, easy maintenance and hygienic design meet strict food processing production standards.
- General Industrial Automation: Delivers precise torque for material handling and small production lines, supporting 24/7 continuous operation with reliable performance.
Common Questions
What is the maximum temperature that the ABB M2QA servo motor can withstand?
The motor has F-class insulation, with a maximum allowable winding temperature of 155°C, and can operate stably in ambient temperatures ranging from -20°C to 40°C.
Can the ABB M2QA be used in humid or corrosive environments like water treatment plants?
Yes. Its IP55 protection rating prevents dust and water spray from entering, and the corrosion-resistant cast iron housing is suitable for humid and slightly corrosive working conditions in water treatment.
Is the ABB M2QA compatible with third-party inverters?
Absolutely. It supports most mainstream inverters on the market, with a wide voltage range of 220-690V and 50/60Hz frequency compatibility, no need for additional modifications.
How long is the service life of the ABB M2QA, and what maintenance is required?
Under normal operating conditions, the service life is up to 10 years. Models with a center height of 71-250mm are equipped with maintenance-free bearings; only regular checks of the terminal box and fasteners are needed.
Does the M2QA meet EU import standards?
Yes. It has passed CE, IEC and ISO 9001 certifications, fully complying with EU market access requirements, and no additional certification is required for import.
Can the mounting method of the ABB M2QA be customized?
Yes. Standard mounting methods include B3, B5 and B35; customized non-standard mounting can be provided according to order requirements, with short lead times.
What is the difference between the ABB M2QA and other ABB servo motor series?
The M2QA series focuses on high efficiency (up to IE5) and multi-industry adaptability, with a more cost-effective positioning, suitable for HVAC, water treatment and food & beverage industries; other series are more oriented to high-precision motion control scenarios.
How to solve the problem of motor overheating during long-term operation?
First, check if the load exceeds the rated power; second, ensure the ventilation around the motor is unobstructed; the built-in PTC thermal protection can also be connected to the control system for automatic overheat protection.
