Highlight:
                                                                                                                                                                                                            Infineon PrimePACK IGBT IPM Module, New Energy Power IPM Module, Infineon PrimePACK IGBT IPM


Type:	IGBT Moduel	Rated Voltage (V):	1200V 1700V 2300V
Rated Current (A):	150A 400A 450A 600A 800A 1000A 1200A 1800A 2400A	Warranty:	Original Manufacturer's Warranty
Pakage:	Original Pakage	Shipping Term:	International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
Freight Charge:	For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote

Type:	IGBT Moduel
Rated Voltage (V):	1200V 1700V 2300V
Rated Current (A):	150A 400A 450A 600A 800A 1000A 1200A 1800A 2400A
Warranty:	Original Manufacturer's Warranty
Pakage:	Original Pakage
Shipping Term:	International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
Freight Charge:	For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote

Infineon PrimePACK IGBT IPM Module For New Energy Power Electronics

Infineon PrimePACK IGBT Modules High Power Density High Reliability for New Energy Power Electronics

PrimePACK IGBT Modules

PrimePACK IGBT Modules deliver exceptional high power density and industry-leading high reliability, making them the ideal power semiconductor solution for a wide range of new energy power electronics applications. Engineered with advanced IGBT chip technologies, optimized packaging design and integrated thermal management features, these modules support high-efficiency energy conversion, stable long-term operation and compact system integration, perfectly meeting the demanding performance and durability requirements of renewable energy generation, energy storage and other new energy power systems.

Key Features

Industry-leading high power density enables compact, high-performance power electronics designs
Superior long-term reliability ensures stable operation under harsh industrial and new energy conditions
Advanced IGBT chip technologies deliver low conduction and switching losses for higher efficiency
Wide voltage and current ranges cover 1200V, 1700V and 2300V applications
Optimized thermal design with integrated NTC sensors for reliable thermal management
Pin-compatible packages simplify system upgrade and reduce assembly time
Ideal for photovoltaic inverters, wind converters, energy storage systems and industrial drives

Technical Specifications

Parameter	Details
Product Series	Infineon PrimePACK™ IGBT Modules
Package Types	PrimePACK™ 2, PrimePACK™ 3, PrimePACK™ 3+
Voltage Class	1200 V, 1700 V, 2300 V
Rated Current	450 A - 2400 A
Chip Technology	IGBT4, IGBT5, IGBT7
Topology Configurations	Half-bridge, three-phase bridge, chopper
Maximum Junction Temperature	175 °C (overload)
Thermal Features	Pre-applied TIM, low thermal resistance, integrated NTC temperature sensor
Isolation & Safety	High creepage distance, high electrical clearance, high CTI insulation
Compatibility	Pin-compatible designs for easy platform upgrade
Typical Applications	Photovoltaic inverters, wind converters, energy storage PCS, industrial drives

Product Models and Applications

Model	Chip Technology	Voltage Class	Rated Current	Max Junction Temp	Key Parameters	Applications
FF450R12KE4P	IGBT4	1200V	450A	175℃	Half-bridge configuration, integrated NTC, high isolation	New energy (wind, photovoltaic), industrial frequency converters
FF400R17KE4P	IGBT4	1700V	400A	175℃	TRENCHSTOP™ technology, low conduction & switching losses	Photovoltaic inverters, energy storage PCS, UPS systems
FF500R17KE4P	IGBT4	1700V	500A	175℃	High current density, robust packaging, excellent thermal cycling	High-voltage frequency converters, rail transit, smart grid
FF1000R17IE4P	IGBT4	1700V	1000A	175℃	Pre-applied TIM, low switching losses, integrated NTC	Large-scale wind power converters, high-power industrial drives
FF1200R17IP5	IGBT5	1700V	1200A	175℃	Emitter-controlled diode, low Vce(sat), high power cycling	Traction drives, high-power converters, wind turbines
6THE150MI	IGBT4	1200V	150A	175℃	Three-phase full-bridge topology, automotive-grade reliability	Commercial vehicle traction inverters, electric commercial vehicles
FF1800R23IE7	IGBT7	2300V	1800A	175℃	TRENCHSTOP™ IGBT7, high DC stability at 1500V	Large-scale solar central inverters, high-voltage energy storage
FF2400R17IE5	IGBT5	1700V	2400A	175℃	.XT interconnection technology, 30% higher output current	Megawatt-level wind power converters, high-power industrial drives
FF600R12IE5P	IGBT5	1200V	600A	175℃	Low switching losses, high efficiency, integrated NTC	Industrial automation, induction heating, photovoltaic string inverters
FF800R23IE7P	IGBT7	2300V	800A	175℃	High reliability, low thermal resistance, strong resistance to harsh conditions	Large-scale solar power plants, high-voltage energy storage PCS

Frequently Asked Questions

Can PrimePACK 2/3/3+ packages be directly replaced?

No. They're pin-compatible but not fully interchangeable—check installation size and heat design first.

Why do modules fail fast in outdoor new energy projects?

Mostly due to poor heat management or exceeding 175℃ junction temperature.

Is extra insulation needed for high-voltage use?

No. They have high creepage distance and meet overseas high-voltage standards.

What's the real difference between IGBT4/5/7?

IGBT4: stable, cost-effective; IGBT5: lower loss; IGBT7: high-power density (ideal for large PV plants).

Can the same heatsink be used for different current models?

Not recommended. Higher current = more heat—match heatsink to thermal resistance.
