Product Details
Place of Origin: Japan
Certification: CE、UL 1557、IEC 60747、IEC 60749、IEC 60068、EN 45545 R22/23/24
Model Number: XHP™ 3
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $5 - $1200
Delivery Time: 3-5Workday
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
IGBT Moduel
|
Rated Current (A):
|
300A 400A 450A
|
Rated Voltage (V):
|
3300V 6300V 6500V
|
Pakage:
|
Original Pakage
|
Warranty:
|
Original Manufacturer's Warranty
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
IGBT Moduel
|
|
Rated Current (A):
|
300A 400A 450A
|
|
Rated Voltage (V):
|
3300V 6300V 6500V
|
|
Pakage:
|
Original Pakage
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Parameter | Specification |
|---|---|
| Product Model | XHP™ 3 IGBT Module |
| Blocking Voltage | 4500V - 6500V |
| Continuous Current | 225A - 450A |
| Topology Structure | Trench Gate Field-Stop IGBT |
| Junction-to-Case Thermal Resistance (Rth(jc)) | As low as 26.1K/kW |
| Switching Loss | Optimized by up to 30% |
| Enhanced Insulation Withstand | 10.4kVAC / 60s |
| Junction Temperature Range | -55°C to 150°C |
| Parasitic Inductance | ≤ 25nH |
| Substrate Material | AlSiC (Aluminum Silicon Carbide) |
| Typical Applications | Wind Power Converters, Medium Voltage Drives, High Power UPS |
| Overseas Model No. | Blocking Voltage | Continuous Current | Key Parameters | Corresponding Industries/Applications |
|---|---|---|---|---|
| FF 450 R 33 T 3 E 3 | 3300V | 450A | Half-bridge topology, 6kV insulation, trench gate field-stop structure, Rth(jc) ≤28K/kW | Medium-voltage drives, traction systems, commercial/construction/agricultural vehicles (CAV) |
| FF 450 R 33 T 3 E 3_B5 | 3300V | 450A | Half-bridge topology, 10.4kV enhanced insulation, low parasitic inductance (≤25nH), AlSiC substrate | Medium-voltage drives, heavy-duty industrial equipment, traction converters for rail transit |
| FF 2000 UX TR 33 T 2 M 1 | 3300V | 400A | Trench gate field-stop structure, 10.4kV insulation, junction temperature range -55°C~150°C | Rail transit traction systems, green railway applications, high-power UPS systems |
| FF 2600 UX TR 33 T 2 M 1 | 3300V | 450A | Trench gate field-stop structure, 10.4kV insulation, optimized switching loss (30% reduction) | Rail transit traction systems, green railway applications, medium-voltage drives |
| FF 300 R 65 T 3 E 3 | 6500V | 300A | Half-bridge topology, 6kV insulation, Rth(jc) =26.1K/kW, low switching loss | Wind power converters, high-voltage industrial drives, large-scale power conversion systems |
| FF 300 R 65 T 3 E 3_B5 | 6500V | 300A | Half-bridge topology, 10.4kV enhanced insulation, AlSiC substrate, ≤25nH parasitic inductance | Wind power converters, high-voltage medium drives, harsh-environment industrial power systems |
| FF 400 R 45 T 3 E 3 | 4500V | 400A | Trench gate field-stop structure, 10.4kV insulation, optimized heat dissipation, switching loss reduced by 30% | Wind power converters, high-power UPS, medium-voltage drives in harsh industrial environments |
