Product Details
Place of Origin: Germany
Certification: CE 、UL/cTUVus 、PROFINET、ACMA、RoHS
Model Number: ACS/ACM36、AHS/AHM36、AFS/AFM60、ANS/ANM58、A3M60、ELM35
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $20 - $1299
Delivery Time: 3-5Workday
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
Encoder
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Encoder
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Series & Models | Core Parameters | Applicable Industries |
|---|---|---|
| ACS36 (Single-turn), ACM36 (Multi-turn) Compact Analog Series |
• Resolution: Up to 3723 steps (single-turn); 3723×16 steps (multi-turn) • Interface: Analog (0-10V/4-20mA) • Shaft: 6mm solid shaft; Flange: Servo flange • Protection Class: IP65 • Operating Temperature: -30℃~+80℃ • Feature: Built-in membrane button for on-site teaching and range setting |
AGV, Industrial Vehicles, Commercial Vehicles, Packaging Machinery, Logistics Equipment, Medical Machinery |
| AHS36 (Single-turn), AHM36 (Multi-turn) Compact Full Magnetic Series |
• Resolution: Up to 14bit (16384) single-turn; Up to 26bit (14bit×12bit) multi-turn • Interface: SSI, IO-Link, CANopen, SAE-J1939 • Shaft: 6/8/10mm solid shaft; Blind hollow shaft; Flange: Servo/Clamping/Blind hollow shaft flange • Protection Class: Basic IP65; Advanced IP66/67; INOX Version IP69K • Operating Temperature: Basic -20℃~+70℃; Advanced -40℃~+85℃ • Feature: Full magnetic sensing, diagnosis (temperature/running time), IO-Link intelligent data processing |
AGV, Industrial Vehicles, Commercial Vehicles, Packaging Machinery, Wood Processing, Logistics, Food & Beverage (INOX Version) |
| AFS60/AFM60 Series 1. AFS/AFM60 Ethernet 2. AFS/AFM60 SSI High-Resolution Series |
• Resolution: Up to 18bit (262144) single-turn; 18bit×12bit (262144×4096) multi-turn • Interface: PROFINET, EtherNet/IP, EtherCAT (Ethernet); SSI (SSI Version) • Shaft: 6/10mm solid shaft; 8/10/12mm blind hollow shaft; Flange: Servo/Clamping • Connection: M12 socket (2×4-pin or 1×4-pin) • Protection Class: IP65/IP67 • Operating Temperature: -40℃~+85℃ • Feature: Web server parameterization, diagnosis (temperature/fault warning), programmable |
Industrial Robots, Automated Production Lines, Servo Drives, Semiconductor Equipment, Precision Machine Tools, Logistics Sorting Lines |
| ANS58 (Single-turn), ANM58 (Multi-turn) PROFINET+IRT High-Resolution Series |
• Resolution: Up to 18bit single-turn; 18bit×12bit multi-turn • Interface: PROFINET IO+IRT (Isochronous Real-Time), SSI • Shaft: 10mm solid shaft; Flange: Clamping/Servo • Protection Class: IP65/IP67 • Operating Temperature: -40℃~+85℃ • Feature: IRT synchronization, high vibration and shock resistance, suitable for high-speed dynamic positioning |
High-Speed Automated Production Lines, Synchronous Drive Systems, Robot Joints, Printing & Packaging (High-Speed Registering) |
| A3M60 Series PROFIBUS/Industrial Bus Series |
• Resolution: 14bit single-turn; 14bit×17bit (16384×131072) multi-turn • Interface: PROFIBUS, SSI, IO-Link • Shaft: 6mm solid shaft; Flange: Servo • Protection Class: IP65/IP67 • Operating Temperature: -40℃~+85℃ • Feature: Compact design, bus compatibility, suitable for distributed control |
Textile Machinery, Injection Molding Machines, Wind Power Equipment, Material Conveyor Lines |
| ELM35 Series Servo Feedback Mechanical Multi-Turn Series |
• Resolution: Up to 24bit single-turn • Interface: EnDat 2.2, BiSS C • Shaft: 6mm solid shaft; Flange: Servo • Protection Class: IP65 • Operating Temperature: -25℃~+85℃ • Feature: Mechanical gear multi-turn (battery-free maintenance), high rigidity, vibration and shock resistance |
Servo Motors, Industrial Robot Joints, CNC Machine Tools, Precision Motion Control Equipment |
