40mm-700mm Sensing Distance Omron Fiber Optic Sensor High Speed Response

Fiber Optic Sensor with High Precision Anti-interference and High-speed Response for Industrial Automation

High precision anti-interference high-speed response sensors designed for electronic assembly and automotive manufacturing applications.

Omron Fiber Optic Sensors deliver exceptional precision detection, robust anti-interference performance, and ultra-fast response times, meeting the demanding requirements of electronic assembly, automotive manufacturing, and various industrial production lines for stable and efficient on-site sensing.

Core Features

Ultra-high precision detection with ≤100μm resolution and 0.5% repeatability for micro and transparent objects
30μs fast response with anti-electromagnetic interference for zero false or missed detection on high-speed lines
IP67 industrial protection with -40℃ to 70℃ operating range and corrosion/dust/oil resistance
One-key teaching functionality requiring no alignment for quick installation and commissioning
500+ models available including through-beam, diffuse reflective, and limited reflection types
Maximum 20m sensing distance with high accuracy for long-range detection
Industry universal compatibility for electronics, automotive, lithium battery, and packaging manufacturing

Product Models & Specifications

Through-beam Type (Fiber Sensor Head)

Model	Core Parameters	Matching Amplifier	Applicable Industries
E32-T17L	Sensing distance: 20m; Protection class: IP67; Operating temp: -40℃~70℃; Fiber bending radius: 10mm; Cable length: Customizable, cuttable	E3X-NA/E3X-HD Series	Automotive manufacturing (body welding positioning), warehousing & logistics (large part detection)
E32-T11N 2M	Ultra-small; Fiber diameter: φ0.25mm; Min bending radius: 1mm; Heat resistance: 120℃; Cable length: 2m, cuttable	E3X-NA/E3X-HD Series	Medical equipment (precision part assembly), semiconductor (chip packaging)
E32-T51V	Vacuum resistant; M4 screw; Heat resistance: 120℃; Protection class: IP67; Operating temp: -40℃~70℃	E3X-NA/E3X-HD Series	Vacuum production line (semiconductor wafer manufacturing)
E32-D16	Long-distance detection; Protection class: IP67; Response time: 30μs; Suitable for high-speed production lines	E3X-NA/E3X-HD Series	Automotive (transmission part detection), lithium battery (cell tab positioning)
E32-T21L	Sensing distance: 10m; Protection class: IP67; Operating temp: -25℃~70℃; Fiber bending radius: 15mm	E3X-NA/E3X-HD Series	Automotive (chassis part inspection), heavy industry (large component positioning)
E32-T31	Fiber type: Plastic; Sensing distance: 5m; Protection class: IP54; Cable length: 2m	E3X-NA Series	General manufacturing (conveyor line part detection), packaging (carton positioning)

Diffuse Reflective Type (Fiber Sensor Head)

Model	Core Parameters	Matching Amplifier	Applicable Industries
E32-D61	Sensing distance: 40-700mm; Protection class: IP67; Response time: 30μs; Anti-electromagnetic interference	E3X-NA/E3X-HD Series	Electronic manufacturing (PCB component detection), packaging (label positioning)
E32-D21-S3 2M	M4 cylindrical head; Sensing distance: 370mm; Protection class: IP67; Bending radius: 10mm; Cable length: 2m, cuttable	E3X-NA/E3X-HD Series	Lithium battery (electrode edge detection), 3C (micro part assembly)
E32-T15Y 2M	Square head: 15×8×3mm; Sensing distance: 1400mm; Protection class: IP67; Cable cuttable	E3X-NA/E3X-HD Series	3C manufacturing (mobile phone middle frame detection), electronic assembly (micro component identification)
E32-D31	Sensing distance: 10-300mm; Plastic fiber; Protection class: IP54; Operating temp: -25℃~70℃	E3X-NA Series	Food & beverage (bottle cap detection), packaging (film position detection)
E32-D71	Long-distance diffuse reflection; Sensing distance: 100-1500mm; IP67; Anti-dust and oil	E3X-HD Series	Automotive (exterior part inspection), logistics (package size detection)

Limited Reflective Type (Fiber Sensor Head)

Model	Core Parameters	Matching Amplifier	Applicable Industries
E32-A08 2M	Optimized for transparent objects; Sensing distance: 20mm; Protection class: IP40; Bending radius: 25mm; Cable length: 2m, cuttable	E3X-NA/E3X-HD Series	Photovoltaic (glass substrate detection), semiconductor (wafer positioning)
E32-A11	Sensing distance: 10mm; Fiber diameter: φ1mm; Protection class: IP40; Operating temp: -25℃~70℃	E3X-NA Series	Semiconductor (chip pin detection), 3C (transparent shell detection)
E32-A21	Sensing distance: 30mm; Optimized for small transparent parts; Bending radius: 15mm	E3X-NA/E3X-HD Series	Lithium battery (transparent film detection), packaging (transparent bottle inspection)

Coaxial Displacement Type (Fiber Sensor)

Model	Core Parameters	Matching Amplifier	Applicable Industries
ZW-7001	Resolution: 0.01μm; Sensing range: 0-10mm; Response time: 1ms; High precision displacement detection	Integrated amplifier	Precision machining (dimensional measurement), semiconductor (wafer thickness detection)
ZW-7002	Resolution: 0.05μm; Sensing range: 0-20mm; Protection class: IP54; High stability	Integrated amplifier	Automotive (precision component flatness detection), 3C (part step measurement)
ZW-300A	White light confocal; Sensing range: 0-3mm; Resolution: 0.001μm; For ultra-precision detection	Integrated amplifier	Semiconductor (chip defect detection), medical equipment (precision part measurement)

Color Fiber Amplifier (Matching All Fiber Heads)

Model	Core Parameters	Compatible Fiber Heads	Applicable Industries
E3NX-CA11	Color recognition; Response time: 10μs; Output type: NPN/PNP; Anti-interference design	All E32 series fiber heads	Packaging (color label detection), electronic manufacturing (color component sorting)
E3NX-CA21	Multi-color setting; Digital display; IP67 protection; Operating temp: -10℃~55℃	All E32/ZW series fiber heads	Food & beverage (color sorting), 3C (color part assembly inspection)

Technical Specifications

All models support NPN/PNP output (except integrated amplifier models), compatible with most overseas PLCs. Fiber cables of most models are cuttable; please confirm the minimum bending radius before cutting to avoid damage.

Frequently Asked Questions

Q1: Can it detect transparent objects like glass or plastic film?

Yes, optimized for transparent materials, stable detection without extra adjustment.

Q2: Will it be interfered by electromagnetic equipment like frequency converters?

No, built-in anti-interference chip, resists EMI well, zero false alarms.

Q3: How to calibrate it quickly on the production line?

One-key teaching, just press the button, no professional skills needed.

Q4: Is it suitable for dusty/oily factory environments?

IP67 protection grade, dust and oil proof, stable operation in harsh conditions.

Q5: Can it match high-speed production lines (over 5m/s)?

30μs fast response, fully adapt to high-speed conveyors, zero missed detection.

Q6: What output types does it support?

NPN, PNP and analog signal, compatible with most PLCs.

Q7: Can the fiber cable be cut to the required length?

Yes, standard 2m cable, free cutting without affecting performance.

Q8: Is it suitable for small part detection (≤0.1mm)?

Ultra-high precision, ≤100μm resolution, stably identify micro workpieces.

Q9: How long is the working temperature range?

-40℃ ~ 70℃, works well in extreme high/low temperature environments.

Q10: Can multiple sensors be used together without interference?

Yes, multi-device anti-interference design, no mutual interference when installed closely.
