Product Details
Place of Origin: Germany
Certification: CE、UKCA、cULus、EU DoC、UK DoC、IEC 61496、ISO 13849、ATEX、IEC 60825 - 1、CDRH 21 CFR 1040、RoHS、REACH、China RoHS
Model Number: G2、G6、W4、W8、W100-2、W18-3 、W27-2/3、W45、W160/WL160、W9、GR18、W12、W26
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $20 - $500
Delivery Time: 3-5Workday
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
Industrial Sensors And Controls
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Industrial Sensors And Controls
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Series | Typical Models | Key Specifications | Applicable Industries |
|---|---|---|---|
| G2 (Ultra-Small) | GTB2S-N1451, GTB2S-P5451, GSE2S-N1311, GTB2S-P1451, GTB2F-P1131, GTB2F-N1131, GSE2S-P1311, GTB2S-P1331 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Detection Principle: Diffuse Reflection, Retro-Reflective; Ultra-compact size | 3C Electronics Assembly, Micro Machinery, Precision Sorting, Small Part Handling |
| G6 (Mini-Size) | GTE6-N1211, GTE6-P1211, GTB6-P1211, GL6-P4211, GL6G-N4411, GSE6-N4111, GSE6-P4112 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red PinPoint LED; Detection Range: Diffuse (max 300mm), Background Suppression (max 400mm), Retro-Reflective (max 7.2m), Through-Beam (max 15m); NPN/PNP optional | Logistics, Electronics Manufacturing, Food & Beverage, Automotive Components, Packaging, Transparent Object Detection |
| W4 (Micro Cylindrical) | WTB4S-3N1361, WSE4S-3P1430V, WL4SL-3P2232, WTB4FP-22161120A00, WLG4S-3P2232V | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Cylindrical design, compact structure; Fast response | Miniature Automation Equipment, 3C Assembly Lines, Precision Conveying, Small Part Detection |
| W8 Inox (Hygienic) | WSE8-P3331V, WSE8-N3331V, WSE8-P3332V, WSE8-N3332V | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Housing: Stainless Steel; Through-Beam (max 45m sensing distance) | Food & Beverage, Pharmaceutical, Medical Equipment, Hygienic Cleaning Scenarios |
| W100-2 (Micro Flat) | WT100-2N1419, WL100-2P1439, WS100-2N1419, WE100-2N1419, WT100-2P1419 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Size: 11×31×20mm; Detection Range: Diffuse (max 1m), Through-Beam (max 20m) | Warehousing & Logistics, 3C Electronics Assembly, Small Machinery, Space-Limited High-Speed Conveyors |
| W18-3 (Cylindrical) | VS18-4N3140V, WS18-3P110, WLF18-3V930, WE18-3P110, WSE18-3N110 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red/Infrared LED; Thread: M18; Detection Range: Through-Beam (max 20m), Retro-Reflective (max 7m) | Automotive Welding, Material Conveying, Machine Tool Loading/Unloading, Oily/Dusty Industrial Scenarios |
| W27-2/3 (Long-Range) | WTB27-3K2411, WTB27-3N2413, WTB27-3P2411, WT27-2R810, WTB27-3P2441S03 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red/Infrared LED; Background Suppression (max 2500mm); ATEX Certified for Explosion-Proof | Explosion-Proof Chemical Industry, Large-Scale Warehousing, Logistics Sorting, Long-Distance Detection Scenarios |
| W45 (Flat Long-Range) | WT45-R660, WT45-P660, WT45-N660, WL45-R660, WL45-P660 | Supply Voltage: 10-30V DC; Protection Class: IP67; Temperature Range: -40~+60°C; Flat Design; Background Suppression, Fast Response | Automotive Assembly, Lithium Battery Production, Space-Limited Precision Equipment, High-Speed Detection |
| W160/WL160 (Compact) | WL160-F340, WL160-F440, WL160T-E212, WL160T-F412, WL160T-P212, WL160T-N412 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Compact structure, multiple detection modes | General Automation, Packaging Machinery, Conveying Systems, Universal Object Detection |
| W9 (Long-Range Cylindrical) | WT9-2N130, WT9-2P130, WS9-2N130, WE9-2N130, WL9-2P130 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Cylindrical design, long detection range | Large-Scale Conveying, Warehouse Logistics, Long-Distance Object Sensing, General Industrial Automation |
| GR18 (Energy-Saving) | GRTE18-N1117, GRTE18-P1117, GRB18-P1117, GRL18-N1117, GRS18-P1117 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Energy-saving design, stable detection performance | Automotive Components, Packaging, Logistics Sorting, General Industrial Automation |
| W12 (Laser Type) | WT12-2B550, WL12-2B550, WS12-2B550, WE12-2B550, WT12L-2B550 | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Laser; High precision, small light spot | Precision Detection, Small Part Positioning, High-Accuracy Assembly Lines, 3C Electronics |
| W26 (Safety Type) | WSU26-3, WEU26-3, WSU26-3P, WEU26-3N | Supply Voltage: 10-30V DC; Protection Class: IP67; Light Source: Visible Red LED; Safety-oriented design, anti-interference | Safety Protection for Industrial Equipment, Dangerous Operation Zones, Automated Logistics |
