Product Details
Place of Origin: Germany
Certification: UL、cULus、CSA、CE 、ATEX 、IECEx
Model Number: UB UC UMC UGB UDC UBE UBEC
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $50-$1000
Delivery Time: 3-5Workday
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
Industrial Sensors And Controls
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Industrial Sensors And Controls
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Series | Model | Sensing Range | Key Parameters | Protection Level | Output Type | Certifications | Applicable Industries |
|---|---|---|---|---|---|---|---|
| UB100 Series | UB100-F77-E0-V31 | 10-100 mm | Mini design, 850 kHz, program input, ≤45 ms response delay, 10-30 V DC, ripple 10% SS | IP67 | 1 NPN NO switch output | cULus Listed (Class 2 Power Source) | Consumer electronics, small parts assembly, lab automation |
| UB100 Series | UB100-F77-E2-V31 | 10-100 mm | Mini design, 850 kHz, program input, ≤45 ms response delay, 10-30 V DC, ripple 10% SS | IP67 | 1 PNP NO switch output | cULus Listed (Class 2 Power Source) | Consumer electronics, small parts assembly, lab automation |
| UB120 Series | UB120-12GM-E5-V1 | 15-120 mm | 850 kHz, 9 ms delay, 10×10 mm target, ultra-narrow beam, 10-30 V DC | IP67 | PNP switchable | cULus Listed | Electronics assembly, small parts handling, medical device packaging |
| UB300 Series | UB300-18GM40-I-V1 | 30-300 mm | Short 40 mm design, 380 kHz, 10-30 V DC, ripple 10% SS, temperature compensation | IP67 | 1 4-20 mA analog output (short-circuit/overload protected) | cULus Listed | Material handling, packaging lines, automotive component detection |
| UB400 Series | UB400-F77-E2-V31 | 25-400 mm | 300 kHz, ≤75 ms delay, 20×20 mm target, mini design, 20-30 V DC | IP67 | PNP NO/NC | cULus Listed | Food packaging, consumer electronics, lab automation |
| UB500 Series | UB500-18GM75-I-V15 | 30-500 mm | 380 kHz, ~50 ms response delay, 10-30 V DC, 0.13 mm resolution, 1 sync connection | IP67 | 1 4-20 mA analog output | cULus Listed (Class 2 Power Source) | Automotive assembly, material handling, logistics sorting |
| UB500 Series | UB500-30GM-E5-V15 | 20-500 mm | Selectable lobe width, 5 output functions, program input, 10-30 V DC, temperature compensation | IP67 | 1 PNP switch output (programmable NO/NC) | cULus Listed | Automotive assembly, packaging, material handling |
| UB1000 Series | UB1000-18GM40-SE2-V1 | 0-1000 mm | Single head system, 40 mm short design, 10-30 V DC, function indicators (360° visible) | IP67 | PNP NO switch output | cULus Listed (Class 2 Power Source) | Conveyor lines, packaging, medium-size component detection |
| UB1000 Series | UB1000-18GM40A-SE2-V1 | 0-1000 mm | Single head system, 40 mm short design, 10-30 V DC, M12 4-pin connector, nickel-plated brass housing | IP67 | PNP NO switch output | cULus Listed (Class 2 Power Source) | Conveyor lines, packaging, medium-size component detection |
| UB1000 Series | UB1000-18GM40A-SE2-V1-Y205349 | 0-1000 mm | Single head system, 40 mm short design, 10-30 V DC, M12 4-pin connector, nickel-plated brass housing | IP67 | PNP NO switch output | cULus Listed (Class 2 Power Source) | Conveyor lines, packaging, medium-size component detection |
| UB1000 Series | UB1000-18GM75-E5-V15 | 100-1000 mm | 5 output functions, selectable lobe width, 10-30 V DC, temperature compensation | IP67 | 1 PNP switch output (programmable NO/NC) | cULus Listed (Class 2 Power Source) | Automotive assembly, large part positioning, logistics |
| UB1000 Series | UB1000-18GM75-I-V15 | 100-1000 mm | Adjustable measurement window, selectable lobe width, 10-30 V DC, 4-20 mA analog output | IP67 | 1 4-20 mA analog output | cULus Listed (Class 2 Power Source) | Automotive assembly, large part positioning, logistics |
| UB2000 Series | UB2000-30GM-E5-V15 | 80-2000 mm | 175 kHz, ≤150 ms delay, sync function, 5 output functions, program input, 10-30 V DC | IP67 | PNP switchable | cULus Listed (General Purpose) | Warehousing, AGV navigation, large component positioning |
| UB2000 Series | UB2000-F42-I-V15 | 80-2000 mm | Minimal dead band, teach function, 10-30 V DC, 4-20 mA analog output, temperature compensation | IP67 | 1 4-20 mA analog output | cULus Listed (Class 2 Power Source) | Smart factory, AGV obstacle avoidance, material stacking detection |
| UB2000 Series | UB2000-F42-U-V15 | 80-2000 mm | Minimal dead band, teach function, 10-30 V DC, temperature compensation, insensitive to compressed air | IP67 | Analog output (4-20 mA/0-10 V) | cULus Listed | Smart factory, AGV obstacle avoidance, material stacking detection |
| UB3000 Series | UB3000-30GM-E5-V15 | 200-3000 mm | 150 kHz, ≤200 ms delay, sync function, 10-30 V DC, temperature compensation | IP67 | PNP switchable | cULus Listed | Heavy industry, port cargo handling, large warehouse stacking |
| UB4000 Series | UB4000-30GM-E5-V15 | 200-4000 mm | 85 kHz, ≤325 ms delay, 5 output functions, program input, 10-30 V DC, ≤50 mA no-load current | IP65 | 1 PNP switch output (programmable NO/NC) | cULus Listed (General Purpose), CSA Listed | Heavy industry, mining, port cargo handling |
| UC500 Series | UC500-18GS-2EP-IO-V15 | 50-500 mm | IO-Link interface, 380 kHz, temperature compensation, 10-30 V DC, adjustable sensitivity | IP67 | PNP switch output + IO-Link | cULus Listed, CE | Smart factory, industrial IoT, automated production lines |
| UC800 Series | UC800-F77S-EP-IO-V31 | 80-800 mm | IO-Link interface, mini design, 850 kHz, 20-30 V DC, high switching frequency | IP67 | PNP switch output + IO-Link | cULus Listed, CE | Consumer electronics, packaging, small part detection |
| UC2000 Series | UC2000-30GM-IUR2-V15 | 80-2000 mm | 180 kHz, 65-195 ms delay, IO-Link, RS232 interface, 10-30 V DC, sync option | IP67 | PNP + IO-Link + analog (4-20 mA/0-10 V) | cULus Listed, CE | Smart factory, industrial IoT, automated production lines |
| UC3500 Series | UC3500-30GM70-IE2R2-V15 | 200-3500 mm | ≤±1.5% drift, 10-30 V DC, temperature compensation, anti-interference sync function | IP67 | PNP + 4-20 mA analog | cULus Listed, CE | Liquid level monitoring, bulk material handling, chemical processing |
| UC4000 Series | UC4000-30GM-IUR2-V15 | 200-4000 mm | RS232 interface, 10-30 V DC, sync option, parameterizable via ULTRA 3000 software | IP67 | PNP + IO-Link + analog (4-20 mA/0-10 V) | cULus Listed, CE | Heavy industry, chemical processing, bulk material storage |
| UMC3000 Series | UMC3000-30H-E5-5M-3G-3D | 200-3000 mm | 100 kHz, ≤200 ms delay, stainless steel housing, 10-30 V DC, explosion-proof design | IP68/IP69K | PNP switchable | ATEX, cULus Listed, IECEx | Oil & gas, chemical, hazardous area automation |
| UGB Series | UGB-18GM50-255-2E1 | 20-60 mm (Optimal: 45 mm) | M18 thread, cylindrical design, 18-30 V DC, ripple 10% SS, insensitive to printed/colored/shiny surfaces | IP67 | Dual switch outputs | cULus Listed, CE | Printing, packaging, surface processing |
| UDC Series | UDC-18GM50-255-3E1 | 20-60 mm | Dual ultrasonic sensor, M18 thread, 18-30 V DC, chemical-resistant housing, temperature compensation | IP67 | Analog + switch outputs | cULus Listed, CE | Chemical processing, pharmaceutical, food & beverage (hygienic applications) |
| UBE Series (Through-Beam) | UBE800-F77-SE2-V31 | 0-800 mm (Emitter-Receiver Spacing) | Mini design, high switching frequency, visible LEDs, 20-30 V DC; 12-20 V DC (80% sensitivity) | IP67 | 1 PNP NO switch output | cULus Listed (Class 2 Power Source) | Packaging lines, bottle filling, conveyor line detection |
| UBE Series (Through-Beam) | UBE1000-18GM40-SE2-V1 | 0-1000 mm (Emitter-Receiver Spacing) | Single head system, 40 mm short design, 10-30 V DC, M12 4-pin connector, nickel-plated brass housing | IP67 | 1 PNP NO switch output | cULus Listed (Class 2 Power Source) | Conveyor lines, large part detection, logistics sorting |
| UBE Series (Through-Beam) | UBE1000-18GM40A-SE2-V1 | 0-1000 mm (Emitter-Receiver Spacing) | Single head system, 40 mm short design, 10-30 V DC, M12 4-pin connector, nickel-plated brass housing | IP67 | 1 PNP NO switch output | cULus Listed (Class 2 Power Source) | Conveyor lines, large part detection, logistics sorting |
| UBE Series (Through-Beam) | UBE1000-18GM40A-SE2-V1-Y205349 | 0-1000 mm (Emitter-Receiver Spacing) | Single head system, 40 mm short design, 10-30 V DC, M12 4-pin connector, nickel-plated brass housing | IP67 | 1 PNP NO switch output | cULus Listed (Class 2 Power Source) | Conveyor lines, large part detection, logistics sorting |
| UBE Series (Through-Beam) | UBE4000-30GM-SA2-V15 | 500-4000 mm (Emitter-Receiver Spacing) | High switching frequency, adjustable sensitivity, 18-30 V DC, reliable for transparent materials | IP67 | 2 PNP switch outputs (complementary NO/NC) | cULus Listed (General Purpose), CSA Listed | Large warehouse, heavy-duty material handling, transparent object detection |
| UBE Series (Through-Beam) | UBE15M-F54-H1-V1 | 0-15000 mm (Emitter-Receiver Spacing) | Multi-head sync, separate evaluation, 16-30 V DC, large lateral distance between emitter/receiver | IP67 | PNP switch output | cULus Listed, CE | Outdoor storage, large warehouse, heavy-duty material handling |
| UBEC Series (Through-Beam) | UBEC300-18GH40-SE2-V1 | 0-300 mm (Emitter-Receiver Spacing) | Short 40 mm design, stainless steel housing, chemical-resistant, 10-30 V DC | IP67 | 1 PNP NO switch output | cULus Listed (Class 2 Power Source) | Chemical processing, pharmaceutical, food & beverage (hygienic applications) |
