Product Details
Place of Origin: Germany
Certification: CE、UL/CUL、EMC、CPA、EAC、CRN、DNV-GL、IO-Link、ISO 、A2LA、3A、EHEDG
Model Number: SI SM SA SB SD SU SV
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $80 - $1000
Delivery Time: 3-5Workday
Payment Terms: L/C,D/A,D/P,T/T,Western Union
|
Type:
|
Industrial Sensors And Controls
|
Warranty:
|
Original Manufacturer's Warranty
|
Pakage:
|
Original Pakage
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
|
Type:
|
Industrial Sensors And Controls
|
|
Warranty:
|
Original Manufacturer's Warranty
|
|
Pakage:
|
Original Pakage
|
|
Shipping Term:
|
International Express（DHL/FEDEX/TNT/UPS/ARAMEX）/Sea Freight / Air Freight / International Special Line
|
|
Freight Charge:
|
For Industrial Equipment (E.G., PLC Modules, Inverters..), Shipping Cost Varies By Package Weight/Volume And Delivery Location. Contact Our Sales Team For A Customized Shipping Solution And Quote
|
| Series | Models | Measuring Principle | Measuring Range | Accuracy | Medium Compatibility | Key Parameters | Protection Class | Industries & Applications |
|---|---|---|---|---|---|---|---|---|
| SI Series (Thermal Flow Sensor) | SI0508, SI1000, SI5000, SI5001, SI5002, SI5004, SI5010, SI5011, SI6000, SI8518, SI9000 | Thermal type | Flow velocity: 0.03…100cm/s; Liquid: 0.1-60L/min; Gas: 0.01-100L/min | ±1%~±10% FS | Liquids (hydraulic oil, coolants, water), gases (compressed air, N₂, CO₂, Ar), weak corrosive media | 316L wetted parts, FKM seal; M18 adapter; IO-Link V1.1, 4-20mA analog output; Working temp: -25…80℃ | IP67 | Mechanical processing, automotive manufacturing, hydraulic systems, general industry |
| SM Series (Magnetic-Inductive Flow Meter) | SM0505, SM2000, SM2001, SM2004, SM2100, SM2130, SM2400, SM2404, SM2500, SM2601, SM2604, SM4020, SM6000, SM6004, SM6010, SM6050, SM6400, SM6604, SM7000, SM7004, SM7100, SM8000, SM8004, SM8100, SM9000, SM9604 | Magnetic-inductive | 5ml/min~160gpm; 0.1~25L/min (SM6400); 5~300L/min (SM9604) | ±(0.8% MW + 0.2% MEW) to ±1% FS | Conductive liquids, water, hydrous media, food-grade fluids, corrosive media | 316L housing, corrosion-resistant liner; Diverse process connections; 4-digit LED/TFT display; IO-Link, 4-20mA output | IP67, IP69K | Food & beverage, dairy, pharmaceutical, chemical industry, water treatment |
| SA Series (Universal Thermal Flow Sensor) | SA2000, SA2004, SA4100, SA4104, SA4110, SA4114, SA4300, SA4304, SA4310, SA4314, SA5000, SA5004, SA5010, SA5014, SA5040, SA6010, SA6014, SA8000 | Thermal type | Liquid: 0.1~6150gpm; Gas: 1~27000scfm | ±10% FS to ±3% FS | Liquids (hydraulic oil, lubricants, water, alcohol), gases (compressed air, inert gases) | 316L wetted parts, FKM/EPDM seal; Rotatable connector; Flow+temperature dual measurement | IP67 | Automotive, machinery processing, energy management, hydraulic systems |
| SB/SBG/SBY Series (Fast Response Flow Sensor) | SB232, SB233, SB234, SB246, SB257, SB332, SB334, SB432, SBG234, SBG246, SBG257, SBG333, SBG334, SBG346, SBG357, SBN333, SBN346, SBY232, SBY321, SBY323, SBY332, SBY333, SBY334, SBY346, SBY357 | Thermal type | 0.1~50gpm | ±5% FS | Liquids (hydraulic oil, lubricants, water-based media, glycol solutions) | Integrated backflow prevention; No straight pipe runs required; Response time ≤10msec | IP67 | Mechanical processing, hydraulic/pneumatic systems, industrial cooling |
| SD Series (Gas/Compressed Air Special Flow Meter) | SD2000, SD8000 | Thermal mass flow | 0~412scfm | ±3% FS | Gases (compressed air, N₂, CO₂, Ar, inert gases) | 316L housing; Totalizer function; Energy-saving monitoring function | IP67 | Automotive, electronics manufacturing, energy management, pneumatic systems |
| SU Series (Ultrasonic Flow Meter) | SU6031, SU7031, SU8031 | Ultrasonic | 0~52.8gpm | ±5% FS | Clean liquids, corrosive media, food-grade liquids, high-temperature liquids | Non-contact, no wear; No pressure loss; High-temperature, anti-corrosion versions | IP67 | Water treatment, chemical industry, food & beverage, petrochemical |
| SV Series (Water-Based Media Flow Sensor) | SV4200, SV5000 | Thermal type | 0.26~26.4gpm | ±2% FS | Water-based media (water content ≥95%) | Displays flow and temperature; Long straight pipe required | IP67 | Water treatment, industrial cooling systems, water circulation pipelines |
